WIKA operating instructions process transmitter, model UPT-2x
14111166.02 04/2015 EN/DE
EN
8. Conguration via display and operating unit
24. Go back one menu level using [ESC].
Select “Low 0%” and conrm with [↵].
25. Set the initial value of the volume measurement with respect
to 0 % of the lling height (e.g. 0 % lling height corresponds
to 3 litres).
» The cursor moves to the next digit.
» Repeat for each digit.
» Initial value is set.
26. Select “High 100%” and conrm with [↵].
27. Set the end value of the volume measurement with respect
to 100 % of the lling height (e.g. 100 % lling height corre-
sponds to 1,000 litres).
» The cursor moves to the next digit.
» Repeat for each digit.
» Initial value is set.
28. Go back one menu level using [ESC].
Select “Mode” and conrm with [↵].
29. Go back one menu levels using [ESC].
Select “Volume” and conrm with [↵].
» Mode is set to volume.
30. Perform a mounting correction.
→ See chapter 8.5 “Mounting correction (oset)”.
» Volume measurement is congured.
