Windhager FireWIN - Page 38

38
4. For the Service Technician
5s
RESET
Fig. 51
Boiler temperature
(Betriebsphasen)
Info Menü
42
°C
5s
RESET
Fig. 52
5s
RESET
Fig. 53
Betreiberebene
Serviceebene
Information level
MES Module
1
wählen zurück
5s
RESET
Fig. 54
Serviceebene nur für geschultes
Servicepersonal
5sec.
Service level
Pressing the Menu button (Fig. 51) shows the „Operator
level“, „Service level“, „Information level“ and „MES Mo-
dule
1
“ in the display – Fig. 52.
Use the arrow buttons to select the “Service level” sub-
menu – Fig. 52.
Press and hold the Choose button for 5 seconds (Fig. 53).
The display shows „Service level only for trained service
personnel“ – Fig. 54.
1 only displayed when an MESplus control is present and this has been adjusted by
a trained service technician in the basic settings.
Operator level
Service level
Information level
MES Module
1
Choose Back
Boiler temperature
(Operating phases)
Info Menu
42
°C
Operator level
Service level
Information level
MES Module
1
Choose Back
Service level only
for trained service personnel
5s
Press for 5
seconds
Press for 5
seconds
