4. For the Service Technician
4.5.1 Parameters
The following parameters can be selected with the arrow buttons, then confirmed using the Choose button.
– Number of burner starts
– Fuel quantity auger conveyor
– Delivery time ignition phase
– Hysteresis Burner ON
– Maximum value of set temperature
– Set temperature ext. heating requirement
– Type of pellet feed system
– Operating time of suction turbine
– Profile ash removal
– Correction of cleaning interval
– Flue gas thermostat or Air intake/ exhaust flap
– Limits for blower speed
– Minimum operating time with buffer
Number of burner starts
The number of burner starts of the FireWIN is displayed.
Fig. 57
Number of burner starts Back
1.350
Back
Fig. 58
Fuel quantity
Auger conveyor
Actual value 6.0 kg
Range 6.0 kg
Correction 0
Choose Back
Fuel quantity auger conveyor
The calculated fuel quantity (actual value) and the range is displayed in kg/h,
and can be adjusted
FireWIN FW 90 FW 120
Actual value
Factory setting:
Setting range:
6,0 kg/h
±2 kg of range
6,0 kg/h
±2 kg of range
Range
Factory setting:
Setting range:
6,0 kg/h
6,0 – 8,0 kg/h
6,0 kg/h
6,0 – 8,0 kg/h
Correction
Factory setting:
Setting range:
0
±5
0
±5
Fig. 59
Delivery time ignition phase
Actual value 120 s
min. 96 s
max. 144 s
– Save Back +
Fig. 60
Hysteresis Burner ON
Actual value 5 K
min. 0 K
max. 20 K
– Save Back +
Delivery time ignition phase
Fuel quantity in the ignition phase
FireWIN FW 90 FW 120
Factory setting: 120 sek. 100 sek.
Setting range: 100 – 150 sek. 80 – 130 sek.
Hysteresis Burner ON
Switching hysteresis for burner control
Factory setting: 5 K
Setting range: 0 – 20 K
