WinGD W-X82 - Page 489

Operation
8019−1/A1
Winterthur Gas & Diesel Ltd.
5/ 12
3
1
5
2
4
WCH02335
Fig. 3: Drain Valves
1 Level switch (LS3426A) 4 Fuel pump 3.14
2 Drain valve (fuel inlet) 5 HP fuel pipe 3.29
3 Drain valve (fuel outlet)
2015-05
Fuel System 6-cylinders to 8-cylinders
