Maintenance
2124−2/A1
RT-flex58T-D
Winterthur Gas & Diesel Ltd.
1/ 7
Tools: Key to Illustrations:
2 RUD-eye bolts 94040−M16 1 Cylinder block 11 Insulation bandage
1 Device GF 94201 2 Cylinder liner 12 Plate
consisting of: 3 Water guide jacket 13 Tension spring
1 Lifting tool GF 94202 (lower part) 14 Holder
1 Chain GF 94202L 4 Antipolishing ring 15 Screw
1 Shackle GF 94202M 5 Water guide jacket 16 Screw
2 Holders GF 94206 (upper part) 17-19 O-rings
2 Special screws M42 GF 94207 6 Transition tube
4 Suspension straps 94208 7 Connection piece AF Seating surface
1 Assembly tool 94345E 8 Screw DF Sealing surface
9 Centring pin DP Depository for GF 94207
10 Cylinder cover WU Wooden underlay
Overview
1. Preparatory works 1/7.....................................
2. Removal and fitting of cylinder liner 2/7.....................
3. Removal and fitting of antipolishing ring 4/7................
4. Removal and fitting of water guide jacket 5/7................
5. Removal and fitting of insulation bandage 6/7...............
6. Laying down and raising cylinder liner 7/7..................
1. Preparatory works
⇒ Drain cylinder cooling water from the respective cylinder and remove cylinder
cover (see 2708−1).
⇒ Remove piston together with piston rod gland (see 3403−1 and 2303−1).
⇒ Separate all piping connections for cylinder oil from the lubricating quills. All
lubricating quills must be removed whenever a cylinder liner is being
pulled out (see 2138−1) .
Remark: Pay attention to:
− General Guidelines for Lifting Tools 0012−1.
Cylinder Liner
Removal and Fitting
2013
