WinGD WARTSILA RT-flex58T-D User Manual

Maintenance
3326−1/A1
RT-flex58T-D
Winterthur Gas & Diesel Ltd.
1/ 3
Tools: Key to Illustrations:
1 Feeler gauge 94238 1 Crosshead pin 6 Guide rail
2 Guide shoe 7 Middle part
3 Guide shoe 8 Screw
4 Guide way in engine column 9 Screw
5 Top end bearing 10 Retaining cover
1. General
On the occasion of an overhaul or when a crosshead has been removed, the op-
portunity should be taken to measure the various running clearances and to
compare them with the values found in the Clearance Table 0330−1, so that pos-
sible wear may be discovered.
FUEL SIDE
15
10
8
7
2
4
4
9
6
4
2
3
3
1
3
2
A
4
003.317/00
4
2013
Crosshead
Checking the Clearances and Fitting the Guide Shoes
