Maintenance
3326−1/A1
RT-flex58T-D
Winterthur Gas & Diesel Ltd.
3/ 3
3. Fitting the guide shoes
The lubricating oil bores in guide shoes 2 and 3 are different in design. Therefore,
guide shoe 2 must not be replaced with guide shoe 3 and vice versa nor ex-
changed!
D Guide rails 6 are screwed on fuel side only!
D Attention must be paid when mounting a guide shoe onto middle part 7 so that
the middle part bears the guide shoe with no clearance whatsoever.
⇒ For this purpose, screws 9 are first to be tightened slightly.
⇒ Then screws 8 are to be tightened slightly by hand and subsequently tight-
ened and secured with 750 Nm or to an angle of 60_.
⇒ Tighten and secure screws 9.
Check with feeler gauge 94238 that there is no clearance between the surfaces of
guide shoe and middle part 7.
2013
Checking the Clearances and Fitting the Guide Shoes
CHECK
