61
Rugged Windows Tablet PC M101BK
Security Function
Security
Password security for user and hard disk lock
Trusted Platform Module (TPM) V2.0
Kensington lock slot
Mechanical Specifications
Dimensions (W x L x H)
271.8 x 198.2 x 22 mm (10.7 x 7.80 x 0.87 inches
Weight
1.35 kg (3 lbs)
Environment Considerations
Operating Temperature
AC Mode: -20°C to 60°C (-4°F to 140°F),
Battery Mode: -10°C to 50°C (32°F to 122°F),
MIL-STD 810G Method 501.5 Procedure II,
Method 502.5 Procedure II
Storage Temperature
-30°C to 70°C (-22°F to 158°F),
MIL-STD 810G Method 501.5 Procedure I,
Method 502.5 Procedure I
Humidity
10% to 90% RH, non-condensing,
MIL-STD 810G Method 507.5 Procedure I
IP Proof
P65, dustproof and waterproof
Shock
MIL-STD-810G Method 516.6 Procedure I
Vibration
MIL-STD-810G Method 514.6 Procedure I
Drop
MIL-STD-810G Method 516.6 Procedure IV, 4 ft to concrete
Standards and Certifications
Safety
CE, FCC Part 2. 1092
Power Management
Power Input
19V DC
Battery
7.4V, typ. 5140 mAh Li-Polymer Battery (2S1P)
7.4V, typ. 10280 mAh Li-Polymer Battery (2S2P,optional)
Battery Operating Time
Operating Time Std. Battery: 6 hours
High Capacity Battery: 12 hours
(tested with MobileMark 2007)
AC Adapter
100-240V, 50-60Hz / 19V DC
AC Adapter Certificate
Compliant with the BS546, BS 546A, SANS 164-1,
SABS 164-1 and IA16A3 standards
Power Plug Type
BS 546 A Type M plug, 2 POLE-3 WIRE GROUNDING (2P+E), Power
Rating: 15A - 16A 250
1. Total usable memory will be less depending upon actual system configuration.
2. 1D/2D Barcode Reader and HF RFID Reader are mutually exclusive options.
3. Length measurements do not include protrusions. Weight varies with options.
4. The drop test with high-capacity battery must come with hand strap.
5. Measured at dimming LCD brightness. Varies depending on the usage conditions, or when an external
device is attached.
