60
Appendix
Appendix B: Technical Specification
Model Name
M101BK
System Specifications
Processor
Intel® Quad-Core™ N2930 Bay Trail-M,1.83GHz
System Memory
4GB SODIMM DDR3L-1600 (up to 8GB)
Storage
64GB M.2 SATA SSD (up to 256 GB)
Operating System
Windows® 10 IoT Enterprise
Display Specifications
Size / Technology
8-inch LED backlight
Resolution
1280 x 800
Brightness
500 nits with optical bonding
Contrast Ratio
800:1
Number of Colors
24 bit RGB
Touch
Multi-Touch Projective Capacitive, withstand repetitive typing, and
scratch resistant throughout the life span
Wireless Communications
WLAN
802.11 a/b/g/n/ac
Bluetooth
Bluetooth 4.0 Dual Mode
GPS
GPS, Galileo
WWAN
Optional 4G (LTE, HSPA+, GSM/GPRS/EDGE,
EV-DO Rev A, 1 x RTT)
System I/O, Buttons and Indicator
Speaker
2 x Stereo Speaker (80dB output)
Ethernet
Compliant with the 1 Gb/s Ethernet 802.3 specifications
External I/O
1 x 30-pin Combo Conn for Giga-LAN or RS232, 1 x USB 3.0,
1 x 3.5 mm Audio Combo Conn. (Mic in or Line Out),
1 x Micro SD Card Slot, 1 x Micro HDMI, 1 x Power Jack
Physical Keyboard
ISO/IEC 9995-3 QWERTY Keypad ,
IP65 water and dust proof, with LED backlight
(keypad dimensions : min. 10x10mm)
Physical Buttons
1 x Power, 10 x Function Keys
LED Indicators
Power, Battery, HDD, RF
Data Capture
Camera
5MP Auto-Focus Camera with LED Flash at rear
Barcode Reader
Optional short range 1D/2D Barcode Reader
HF RFID
Optional HF RFID Reader
UHF RFID
Optional UHF RFID Reader
