1128500 WPC 2000 User Manual
1-10 Introduction
* Shadow light curtain required
Options Shadow V, Shadow VI, Shadow VII, or Shadow 8 Light Curtain
Heights from 6 to 60 in., scanning ranges from 23’ to 65’. Refer to Shadow
literature for more information.
Firmware
Muting for Shadow light curtain on the upstroke. Two-hand only. One-
hand*, two-hand or foot operation*. Automatic Single-stroke (External Trip).
Continuous On-demand. Auto compensated top-stop (ACTS). High Speed
(>500 SPM).
Selector Switches
Mode (One-hand*, two-hand, or foot operation*). Micro-inch on/off.
Automatic (single-stroke or continuous on-demand) on/off to slave the
press to an external device. Operator station select for either of two
operator stations or both operator stations.
4-Channel Programmable Cam
Enclosure: 5.41 x 7.38 x 3.48 in. (137.4 x 187.5 x 88.4 mm), shock-mounted
Relay: SPDT 0-3A resistive at 240V (standard)
DC Solid State: SPST 2A at 5-60 Vdc optional
AC Solid State: SPST 1A at 70-250 Vac (optional)
Foot Switch
Safety switch for foot actuation* (1-hand/2-hand/foot firmware required).
One-hand Control
Control for one-hand actuation* (1-hand/2-hand/foot firmware required).
Counterbalance Air Pressure Switch
12-150 PSI. Monitors counterbalance air supply (uses one custom input).
Bar Mode Control
Allows manual turning of crankshaft.
Motor Control and Custom Packages
Refer to Press Control/Motor Starter literature, and/or contact your Wintriss
representative or factory for more details.
Option 1 User Inputs
Provides 20 additional non-control-reliable inputs and 4 additional control-
reliable, cross-checked input pairs for customized status codes.
Eight inputs are E-stop
Ten inputs are Top-stop
Two inputs are E-stop/Lockout
Two cross-checked pairs are E-stop
Two cross-checked pairs are E-stop/Lockout
Table 1-1. WPC 2000 Specifications (Cont)
