Sawmill Setup
Portable Sawmill Setup
3
3-7 60HDdoc081208 Sawmill Setup
operating the sawmill controls. Operating the controls with-
out the engine running will result in power drainage from
the battery.
3. Remove the fenders by lifting them out of the slots.
CAUTION! To prevent fender damage, remove fenders
before operating sawmill or loading logs.
4. Use the carriage forward/reverse switch (left side of control box) to move the cutting head
toward the front end of the mill.
5. Lower and set the remaining rear outriggers. Level the sawmill by turning each outrigger
adjustment bolt clockwise to raise a given sawmill end, or counterclockwise to lower it.
Adjust all outriggers evenly to avoid twisting the mill frame by jacking one outrigger higher
than the others.
6. Raise the side supports to prevent the log from falling off the side of the mill when loaded.
See Figure 3-3.
FIG. 3-3
Side Support
Bed Rail
Stop Block
