YOXIMO owner manual
The adaptor output is 12 VDC at 1.0 A. Leaving the adaptor cable plugged in when the YOXIMO
is connected but not in use makes sure the battery is always charged and the terminal is always
ready to use.
Figure 21. Power adaptors for connection to the YOXIMO – European / universal
The power adaptor can be connected either to the YOXIMO or to the cradle, using the socket on
the side of the terminal or the side of the cradle.
plug-in adaptor
universal
mains-adaptor
