YOXIMO owner manual
Cradle
The optional cradle gives you a safe place to put the YOXIMO when you are not using it
immediately. It is ideal for use in vehicles and busy environments indoors. The cradle can also be
used to charge the YOXIMO.
The cradle can be:
• screwed to a wall or other vertical surface
• fixed to a horizontal surface using ruggedised Velcro tape
Without the drop protection attached, the cradle measures 178 mm long x 120 mm wide x 47 mm
high and weighs 120 g.
Without the drop protection attached, the cradle measures 180 mm long x 120 mm wide x 70 mm
high, and weighs 145 g.
The YOXIMO cradle is available in dark grey (colour code ncs s6000-n). The drop protection has
the same colour.
Figure 28. Cradle
1 release spring 4 retaining clip
2 power contacts 5 drop protection
3 release buttons
2
3
1
4
3
5
