om_yxm_techSpecs.fm document release 1.1 last updated 30/9/15
Technical specifications
For part numbers, refer to your vendor’s catalogue
item specification
product name YOXIMO
type mobile payment terminal
keypad backlit ergonomic keypad
display backlit 64k colour display, 44.64mm wide x 33.48mm high (2.2” diagonal), 320
pixels wide x 240 pixels high
card readers chip-card reader conforms to EMV 4.3 Level 1
triple-track magstripe-card reader conforms to ISO 1/2/3
NFC (contactless) reader conforms to EMV 4.3 Level 1
printer integrated thermal graphic printer, easy-paper-load mechanism, paper 58 mm
width and 10 m length
wireless
communication
WiFi, IEEE 802.11 (standard) b/g/n
3G/GSM/GPRS worldwide (850-900-1800-1900-2100 MHz)
interface USB for connection to an ePOS (point of sales) terminal, a PC or as a peripheral
chip security
modules
2 SAM slots type ID 0
1 SIM slot (for GSM/GPRS/Edge/3G)
processing
capabilities
2 x 32 bit ARM™ processor cores
128 Mbytes RAM
128 Mbytes Flash memory
hardware cryptographic accelerators
power supply rechargeable Lithium-Ion battery, 1200 mAh @7.6 V
direct battery charging via power adaptor 220-240 VAC, 50 Hz or 100-120 VAC,
60 Hz
dimensions 190 mm long x 84 mm wide x 46 mm high
weight 380 g (including printer, paper roll and battery)
operating
conditions
operating temperature -10°C to +50°C
operating humidity 20 % to 95 % RH non-condensing
environmental
compliance
RoHS2 directive 2011/65/EU
WEEE directive 2002/96/EC
European directive 1907/2006/EC on Registration, Evaluation, Authorisation and
Restriction of Chemicals (REACH)
software full-featured Linux® operating system
Linux-based development kit (C and Java™
secured remote download of software
