Removing the terminal from the cradle
Figure 31. Removing YOXIMO from its cradle
To remove the YOXIMO from its cradle, put your hand over the YOXIMO and press the two release
buttons on the cradle. A spring on the cradle makes sure that the YOXIMO is released.
Powering the cradle
There are different sockets for the power cable from a mains adaptor and the power cable (hard-
wired or from the cigarette lighter) in a vehicle.
Figure 32. Power inputs on the cradle
1 vehicle power ((hard-wired or from the cigarette lighter)
2 external power cable from mains adaptor
1
2
