YOXIMO owner manual
Fixing the cradle on a countertop or other horizontal surface
You can use the cradle simply by resting it on its four rubber feet. For stability, you can also screw
it to a flat surface.
Before fixing the cradle, make sure there will be enough space to:
• fold the privacy shield in and out
• insert a chip card in the chip-card reader
• slide a magstripe card through the magstripe-card reader
• open the printer cover and replace the paper
To fix the cradle to a flat surface:
1. make sure that the surface is stable
2. put the fixing screws through the oval holes
Fixing screws are not supplied with the cradle. Use screws appropriate for the surface,
and with a maximum diameter of 4.5 mm
Always use two screws to attach the cradle firmly. We recommend screws with a domed
or pan head, as shown.
When you are ready to use the cradle, attach the power cable as described under Powering the
cradle, on page 32
