YOXIMO owner manual
26 public
last updated 30/9/15 document release 1.1 om_yxm_accessories.fm
Shoulder-strap and belt-clip
The carrying case comes with both a shoulder-strap and a belt-clip. To use the belt-clip
1. screw the security stud on to the carrying case
2. slip the belt-clip over your belt: it includes a spring to keep it securely in place
3. slip the security stud into the belt-clip and wait for it to click into place
Pinch the belt-clip open before pulling it off your belt.
Figure 27. Opening the belt-clip
Figure 26. Security stud and belt-clip
1 security stud
2 belt-clip
3 release button – press to take carrying-case off belt-clip
2
3
1
