11
L3130 · L3430 · L3830 · L4630 · L5030, WSM
SPECIFICATIONS
CABIN Type
Note : * Manufacture’s estimate
The company reserves the right to change the specifications without notice.
W10399600
Model
L5030
Manual Transmission GST HST
Engine
Model V2403-MA-E-GST-EU
Type Indirect injection vertical, water-cooled, 4-cycle diesel
Number of cylinders 4
Total displacement 2.434 L (148.5 cu.in.)
Bore and stroke 87 × 102.4 mm (3.4 × 4.0 in.)
Net power 37.3 kW (50.7 HP)*
PTO power
(factory observe)
32.8 kW (44.6 HP)* / 2700 min
−1
(rpm)
31.7 kW (43.1 HP)* /
2700 min
−1
(rpm)
Maximum torque 162.4 N·m (16.6 kgf·m, 119.8 ft-lbs)
Battery capacity 12 V, RC : 133 min, CCA : 582 A
Fuel Diesel fuel No. 1 [below −10 °C (14 °F], Diesel fuel No. 2 [above −10 °C (14 °F)]
Capacities
Fuel tank 43 L (11.4 U.S.gals, 9.5 Imp.gals)
Engine crankcase
(with filter)
8.2 L (8.7 U.S.qts, 7.2 Imp.qts)
Engine coolant 9.2 L (9.7 U.S.qts, 8.1 Imp.qts)
Transmission case 45 L (11.9 U.S.gals, 9.9 Imp.gals)
Dimensions
Overall length
(without 3P)
3245 mm (127.8 in.)
Overall width (min. tread) 1470 mm (57.9 in.)
Overall height 2275 mm (89.6 in.)
Wheel base 1915 mm (75.4 in.)
Min. ground clearance 425 mm (16.7 in.)
Tread
Front 1135 mm (44.7 in.)
Rear 1125 mm (44.3 in.), 1225 mm (48.2 in.), 1325 mm (52.2 in.)
Weight 1840 kg (4057 lbs) 1860 kg (4101 lbs)
Travelling
system
Standard
tire size
Front 9.5-16
Rear 13.6-28
Clutch Dry type single stage
Steering Hydrostatic power steering
Transmission
16 forward and 16 reverse
speeds
24 forward and 16 reverse
speeds
3 speeds
Braking system Wet disk type
Min. turning radius
(with brake)
3.2 m (10.5 feet)
Hydraulic
system
Hydraulic control system Position control
Pump capacity 37.0 L (9.8 U.S.gals, 8.1 Imp.gals) / min.
Three point hitch SAE Category 1
Max. lift
force
At lift points 1750 kg (3860 lbs)
24 in. behind
lift points
1350 kg (2976 lbs)
System pressure 17.7 MPa (180 kgf/cm
2
, 2560 psi)
PTO
Rear PTO SAE 1-3/8, 6 splines
PTO / Engine speed 540 min
−1
(rpm) / 2550 min
−1
(rpm)
540 min
−1
(rpm) /
2660 min
−1
(rpm)
KiSC issued 02, 2007 A
