wsm L503 - Servicing Specifications

2-S2
L3130 · L3430 · L3830 · L4630 · L5030, WSM
CLUTCH
2. SERVICING SPECIFICATIONS
W1013874
Item Factory Specification Allowable Limit
Clutch Pedal Free play 20 to 30 mm
0.78 to 1.18 in.
–
Clutch Stopper Bolt Height 18 to 22 mm
0.70 to 0.87 in.
–
Clutch Disc Disc Surface to
Rivet Top (Depth)
– 0.3 mm
0.012 in.
Clutch Disc Boss to Gear Shaft Backlash
(Displacement
Around Disc Edge)
– 2.0 mm
0.079 in.
Pressure Plate Flatness – 0.2 mm
0.008 in.
Diaphragm Spring Mutual Difference – 0.5 mm
0.020 in.
KiSC issued 02, 2007 A
