L3130 · L3430 · L3830 · L4630 · L5030, WSM
BRAKES
2. SERVICING SPECIFICATIONS
W10138740
Item Factory Specification Allowable Limit
Brake Pedal Free Travel 15 to 20 mm
0.6 to 0.8 in.
–
Brake Lever Link Shaft to Bushing
Brake Lever Link Shaft
Brake Lever Link Bushing
Clearance
O.D.
I.D.
0.12 to 0.25 mm
0.0047 to 0.0098 in.
19.90 to 19.98 mm
0.7835 to 0.7866 in.
20.10 to 20.15 mm
0.7913 to 0.7933 in.
1.0 mm
0.039 in.
–
–
Cam Plate Flatness – 0.3 mm
0.012 in.
Cam Plate and Ball Height 20.9 to 21.1 mm
0.823 to 0.831 in.
20.5 mm
0.8071 in.
Brake Disc Thickness 4.6 to 4.8 mm
0.181 to 0.189 in.
4.2 mm
0.165 in.
Plate Thickness 2.54 to 2.66 mm
0.1000 to 0.1047 in.
2.1 mm
0.0827 in.
KiSC issued 02, 2007 A
