5-S3
L3130 · L3430 · L3830 · L4630 · L5030, WSM
BRAKES
3. TIGHTENING TORQUES
Tightening torques of screws and nuts in the table below are especially specified.
(For general use screws and nuts: See page G-10.)
W10127360
Item N·m kgf·m ft-lbs
Rear wheel mounting screw and nut
Rear wheel mounting stud bolt
ROPS lower frame mounting screw
Cabin mounting bolt and nut
Cabin mount bracket mounting screw
Rear axle case mounting screw (M10)
Rear axle case mounting nut (M10, 9T)
Rear axle case mounting screw (M12)
Rear axle case mounting stud bolt
Brake case mounting screw and nut
Floor seat mounting bolt and nut
Brake case mounting stud bolt
Brake cam lever mounting nut
215
98.1 to 112.8
166.7 to 196.1
124 to 147
166.7 to 196.1
48.1 to 55.9
60.8 to 70.5
77.5 to 90.2
24.5 to 31.4
77.5 to 90.2
196 to 225
38.2 to 45.1
62.8 to 72.5
22
10.0 to 11.5
17 to 20
13.0 to 15.0
17 to 20
4.9 to 5.7
6.2 to 7.2
7.9 to 9.2
2.5 to 3.2
7.9 to 9.2
20 to 23
3.9 to 4.6
6.4 to 7.4
166
72.3 to 83.2
123 to 144
91.0 to 108.0
123 to 144
35.4 to 41.2
44.9 to 52.1
57.1 to 66.5
18.1 to 23.1
57.1 to 66.5
145 to 166
28.2 to 33.3
46.3 to 53.5
