14
L3130 · L3430 · L3830 · L4630 · L5030, WSM
TRAVELLING SPEEDS
[GST Type (with creep speed model)]
The company reserves the right to change the specifications without notice.
W1032246
[HST Type]
The company reserves the right to change the specifications without notice.
W1034865
Model L4630 L5030
Creep gear shift lever High Low High Low
Tire size (Rear) 13.6-24 13.6-28
Shuttle shift
lever
Main gear shift
lever
km/h (mph) km/h (mph)
Forward
(At rated engine
rpm)
1 1.68 (1.0) 0.19 (0.1) 1.77 (1.1) 0.20 (0.1)
2 2.38 (1.5) 0.27 (0.2) 2.51 (1.6) 0.28 (0.2)
3 3.07 (1.9) 0.35 (0.2) 3.24 (2.0) 0.36 (0.2)
4 3.86 (2.4) 0.43 (0.3) 4.07 (2.5) 0.46 (0.3)
5 4.54 (2.8) 0.51 (0.3) 4.78 (3.0) 0.54 (0.3)
6 5.71 (3.5) 0.64 (0.4) 6.02 (3.7) 0.68 (0.4)
7 6.75 (4.2) 0.76 (0.5) 7.12 (4.4) 0.80 (0.5)
8 8.49 (5.3) 0.95 (0.6) 8.95 (5.6) 1.00 (0.6)
9 9.55 (5.9) 1.07 (0.7) 10.07 (6.3) 1.13 (0.7)
10 12.01 (7.5) 1.35 (0.8) 12.66 (7.9) 1.42 (0.9)
11 19.49 (12.1) 2.19 (1.4) 20.54 (12.8) 2.31 (1.4)
12 28.78 (17.9) 3.23 (2.0) 30.34 (18.9) 3.41 (2.1)
Reverse
(At rated engine
rpm)
1 1.40 (0.9) 0.16 (0.1) 1.48 (0.9) 0.17 (0.1)
2 1.98 (1.2) 0.22 (0.1) 2.09 (1.3) 0.23 (0.1)
3 3.22 (2.0) 0.36 (0.2) 3.39 (2.1) 0.38 (0.2)
4 4.76 (3.0) 0.53 (0.3) 5.01 (3.1) 0.56 (0.3)
5 7.07 (4.4) 0.79 (0.5) 7.45 (4.6) 0.84 (0.5)
6 10.01 (6.2) 1.12 (0.7) 10.55 (6.6) 1.18 (0.7)
7 16.24 (10.1) 1.82 (1.1) 17.12(10.6) 1.92 (1.2)
8 23.99 (14.9) 2.69 (1.7) 25.28 (15.7) 2.84 (1.8)
Model L5030
Tire size (Rear) 14.9-26
Shuttle shift lever Range gear shift lever km/h (mph)
Forward
(At rated engine rpm)
L 0 to 6.10 (0 to 3.8)
M 0 to 11.80 (0 to 7.3)
H 0 to 28.60 (0 to 17.8)
Reverse
(At rated engine rpm)
L 0 to 5.50 (0 to 3.4)
M 0 to 10.60 (0 to 6.6)
H 0 to 25.70 (0 to 16.0)
KiSC issued 02, 2007 A
