3-S16
L3130 · L3430 · L3830 · L4630 · L5030, WSM
TRANSMISSION
W1012736
Item N·m kgf·m ft-lbs
(Cabin)
Compressor mounting screw
Cabin mounting bolt and nut
(Manual Transmission)
Main shift base mounting screw
Main shift arm setting screw
Clutch housing bearing holder mounting screw
Stopper screw
(GST)
Joint bolt for GST delivery pipe
Shift pin mounting screw
GST valve mounting screw
Clutch housing bearing holder mounting screw
Stopper screw
Joint bolt for GST delivery pipe and regulating valve
Joint bolt for power steering hose and regulating valve
Joint bolt for delivery pipe and hydraulic pump
Regulating valve mounting screw
Joint bolt
Plate
Regulating valve case and support mounting screw
Lower body mounting hex. socket head cap screw
(HST)
HST control lever setting hex. head screw
Joint bolt for oil cooler pipe
Joint bolt for charge delivery pipe to filter bracket
Cap nut for charge delivery pipe
Port block mounting hex. head screw
Swashplate setting hex. head screw
Cradle bearing bracket mounting hex. head screw
Charge pump case mounting screw
Hex. head plug
Hex. head plug
Regulator mounting hex. head screw
Servo piston and cover mounting hex. head screw
Joint bolt for PTO pipe to PTO clutch valve
24.5 to 29.4
124 to 147
23.5 to 27.5
9.8 to 11.3
48.1 to 55.9
34.3 to 44.1
34 to 39
12.7 to 14.7
42.2 to 48.1
48.1 to 55.9
34.3 to 44.1
34.3 to 39.2
49.0 to 68.6
39.3 to 49.0
17.6 to 20.6
49.0 to 58.8
9.8
9.8
9.8 to 10.8
6.86 to 8.33
34 to 39
39 to 49
49 to 59
98 to 123
28 to 35
28 to 35
28 to 35
30 to 37
56 to 68
6.9 to 8.3
28 to 35
34 to 39
2.5 to 3.0
12.6 to 15.0
2.4 to 2.8
1.00 to 1.15
4.9 to 5.7
3.5 to 4.5
3.5 to 4.0
1.3 to 1.5
4.3 to 4.9
4.9 to 5.7
3.5 to 4.5
3.5 to 4.0
5.0 to 7.0
4.0 to 5.0
1.8 to 2.1
5.0 to 6.0
1.0
1.0
1.0 to 1.1
0.70 to 0.85
3.5 to 4.0
3.5 to 4.0
5.0 to 6.0
10.0 to 12.5
2.9 to 3.6
2.9 to 3.6
2.9 to 3.6
3.1 to 3.8
5.5 to 7.0
0.7 to 0.85
2.9 to 3.6
4.0 to 5.0
18.1 to 21.7
91.1 to 108
17.4 to 20.3
7.2 to 8.3
35.4 to 41.2
25.3 to 32.5
25.3 to 28.9
9.4 to 10.8
31.1 to 35.4
35.4 to 41.2
25.3 to 32.5
25.3 to 28.9
36.2 to 50.6
29.0 to 36.2
13.0 to 15.2
36.2 to 43.4
7.2
7.2
7.2 to 8.0
5.06 to 6.15
25.3 to 28.9
25.3 to 28.9
36.1 to 43.4
72.3 to 90.4
21 to 26
21 to 26
21 to 26
22.4 to 27.5
39.8 to 50.6
5.1 to 6.1
21 to 26
28.9 to 36.1
KiSC issued 02, 2007 A
