G-13
L3130 · L3430 · L3830 · L4630 · L5030, WSM
G GENERAL
(Only the Check Points Different from Those for Tractors with CABIN)
W11154790
(Only the Check Points Different from Those for Tractors with CABIN)
W10606470
No.
Period
Item
Indication on hour meter
Important
Reference
page
50 100 150 200 250 300 350 400 450 500
1
Clogging of air conditioner
condenser screen
Clean Daily –
2 Tension of air conditioner drive belt Adjust ✩ G-29
3 Clogging of inner air filter Clean ✩ G-30
4 Clogging of fresh air filter Clean ✩ G-30
5
Clogging of air conditioner
condenser
Check ✩ G-31
6 Air conditioner pipes and hoses Check G-32
7 CABIN isolation cushion Check G-32
8 Lubricating points Check
Service as required
G-37
9 Washer liquid Check G-37
10 Amount of refrigerant (gas) Check G-38
No.
Period
Item
Indication on hour meter After purchase
Important
Reference
page
550 600 650 700 750 800 1 year 2 years
1
Clogging of air conditioner
condenser screen
Clean Daily –
2 Tension of air conditioner drive belt Adjust G-29
3 Clogging of inner air filter Clean G-30
4 Clogging of fresh air filter Clean G-30
5
Clogging of air conditioner
condenser
Check G-31
6 Air conditioner pipes and hoses Check ✩ G-32
7 CABIN isolation cushion Check ✩ G-32
8 Lubricating points Check
Service as required
G-37
9 Washer liquid Check G-37
10 Amount of refrigerant (gas) Check G-38
KiSC issued 02, 2007 A
