8-S3
L3130 · L3430 · L3830 · L4630 · L5030, WSM
HYDRAULIC SYSTEM
CYLINDER SAFETY VALVE
W10115520
LIFT ARM SUPPORT AND HYDRAULIC CYLINDER
W10118710
Item Factory Specification Allowable Limit
Cylinder Safety Valve Operating
Pressure
19.6 to 22.6 MPa
200 to 230 kgf/cm
2
2845 to 3271 psi
–
Hydraulic Cylinder I.D. 55.000 to 55.074 mm
2.16535 to 2.16827 in.
55.100 mm
2.16929 in.
KiSC issued 02, 2007 A
