8-S22
L3130 · L3430 · L3830 · L4630 · L5030, WSM
HYDRAULIC SYSTEM
Lift Arm Bushing
1. Visually inspect the DX bushings for signs of wear or damage.
(The DX bushing tends to show concentrated wear.)
2. If the DX bushing is worn beyond the alloy portion (A), replace it.
(Reference)
W1020165
Lift arm bushing Alloy thickness (A)
0.57 mm
0.0224 in.
To Next Page
