1-S9
L3130 · L3430 · L3830 · L4630 · L5030, WSM
ENGINE
ENGINE BODY (Continued)
W1013874
LUBRICATING SYSTEM
W1013973
Item Factory Specification Allowable Limit
Cylinder Bore
[Standard]
[Oversize]
D1503-M
D1703-M
D1803-M
V2203-M
V2403-M
D1503-M
D1703-M
D1803-M
V2203-M
V2403-M
I.D.
I.D.
83.000 to 83.022 mm
3.26772 to 3.26858 in.
87.000 to 87.022 mm
3.42519 to 3.42606 in.
83.250 to 83.272 mm
3.27756 to 3.27843 in.
87.250 to 87.272 mm
3.43503 to 3.43590 in.
+ 0.15 mm
+ 0.0059 in.
+ 0.15 mm
+ 0.0059 in.
+ 0.15 mm
+ 0.0059 in.
+ 0.15 mm
+ 0.0059 in.
Engine Oil Pressure At Idle Speed
At Rated Speed
98 kPa or more
1.0 kgf/cm
2
or more
14 psi or more
294 to 441 kPa
3.0 to 4.5 kgf/cm
2
43 to 64 psi
49 kPa
0.5 kgf/cm
2
7 psi
245 kPa
2.5 kgf/cm
2
36 psi
Engine Oil Pressure Switch Working Pressure 49 kPa
0.5 kgf/cm
2
7 psi
–
Inner Rotor to Outer Rotor Clearance 0.03 to 0.14 mm
0.0012 to 0.0055 in.
0.2 mm
0.0079 in.
Outer Rotor to Pump Body Clearance 0.11 to 0.19 mm
0.0043 to 0.0075 in.
0.25 mm
0.0098 in.
Inner Rotor to Cover Clearance 0.105 to 0.150 mm
0.00413 to 0.00591 in.
0.2 mm
0.0079 in.
KiSC issued 02, 2007 A
