Page 5-30 Publication No. 150-041118
Section 5 – Configuration and Programming Rev. A
Sep 2001
PROG: 2=NEXT 3=BACK
ENCRYPTION TYPE=CLR
• Use the cursor/value knobs to input the channel’s encryption type. This option can be CLR (no encryption),
EXT (external encryption), STD (internal encryption on internal transceiver module), or OTAR (internal
encryption with OTAR capability on internal transceiver module). Press the MODE button to go to the next
menu page.
PROG: 2=NEXT 3=BACK
ENCRYPTION KEY= ..
• Use the cursor/value knobs to input the channel’s encryption key. This page will only appear if applicable, i.e.
an encryption type of STD or OTAR was specified above. Press the MODE button to go to the next menu page.
PROG: 2=NEXT 3=BACK
RX BANDWIDTH= STD
• Use the cursor/value knobs to input the channel’s receive bandwidth. Valid options are STD (standard),
NARROW, WIDE, and X-WIDE (extra wide). Press the MODE button to go to the next menu page. Normal
setting is STD.
PROG: 2=NEXT 3=BACK
4=ADVANCED FEATURES
• Typically, the previous channel properties are all you need to specify. Pressing the MODE button will skip over
the “advanced features” menu pages to the page that lets you permanently save your channel.
• Channels using an ITM in the RT-5000 will NEVER require the user to input advanced information.
• Press the DIM button to continue with the “advanced features”.
PROG: 2=NEXT 3=BACK
2ND IF INJECTION= HI
• Use the cursor/value knobs to input the channel’s second I.F. Injection as HI or LO. The default is HI. Press
the MODE button to go to the next menu page.
