l. Peel the sticker off the New Overlay and install the New Overlay. Do not reuse the Old Overlay. Make sure
to align the 7-segment LED. The light symbol should be on the right side. See Figure 97.
2. UI Harness Is damaged:
a. Power down the JoeTap Compact Nitro Fridge by unplugging it from the power supply.
b. Remove the UI Board:
i. Open the JoeTap Compact Nitro Fridge Door and use Utility Knife or similar to get under the existing UI
Overlay and peel it off. See Figure 98.
ii. Remove two (2) screws holding the UI Board in place. See Figure 99.
