Wunder-Bar JoeTap NITCOM - Page 93

Page | 93
26. Ensure that all wires are routed through the cutout in the foam behind the Rear Enclosure, so it is not clamped
between the Rear Enclosure and the NITCOM Refrigerator. See Figure L29.
27. Slide the Rear Bottom Panel under the Lower Lip of the NITCOM Refrigerator so that the Square Cutout aligns over
the Black Power Plug. See Figure L30.
Figure L27: Secure Rear Enclosure to Fridge with Top Left
Screw outside.
Figure L28: Secure Rear Enclosure to Fridge
with all four Screws inside.
Wires routed
through Foam
Cutout in the
Fridge Rear.
Figure L29: Wires routed through Foam Cutout in the Fridge Rear.
