28. Secure the Rear Bottom Panel in place using five (5) Self-Tapping #10-16 Screws into the slots. Use screwdriver with
5/16” Hex Drive to fully insert the Self Tapping #10-16 Screws. See Figure L31.
29. Reinstall the Rear Enclosure Cover. See Figure L32.
Rear Bottom Panel
Lower Lip of Fridge
Figure L30: Bottom Back Panel under the Lower Lip of the Fridge.
Self-Tapping #10-16
screws
Figure L31: Rear Bottom Panel installed.
Figure L32: Rear Enclosure Cover installed.
