5. Load the labels in the tray.
• For long-edge feed, insert labels face up with the top edge toward the front.
• For short-edge feed, insert labels face up with the top edge toward the right.
Note: Do not load paper above the maximum fill line. Overfilling can cause paper jams.
6. Adjust the length and width paper guides to fit the labels.
Xerox
®
AltaLink
®
B8145/B8155/B8170 Series Multifunction Printer User Guide 223
Paper and Media
