2. To open Door A, lift the release lever, then open Door A.
WWaarrnniinngg:: The area around the fuser can be hot. To avoid injury, use caution.
CCaauuttiioonn:: Do not touch the transfer belt. Touching the belt can reduce image quality or damage the
transfer belt. Do not touch the transfer roller. Touching the roller can reduce image quality.
3. Remove the new transfer roller from the packaging. Retain the packaging.
4. To release the used transfer roller from the printer, pinch the orange levers at each end of the transfer roller, as
shown.
262 Xerox
®
AltaLink
®
B8145/B8155/B8170 Series Multifunction Printer User Guide
Maintenance
