2. Grasp the booklet maker handle and pull the unit toward you until the staple cartridges appear on the top edge
of the device.
3. To remove a staple cartridge from the booklet maker, push down on the staple cartridge handle, as shown, then
pull the cartridge out and up.
4. Turn over the staple cartridge.
5. To remove the staple pack from the staple cartridge, press in the green tabs and pull back the handle, then lift
out the staple pack.
272 Xerox
®
AltaLink
®
B8145/B8155/B8170 Series Multifunction Printer User Guide
Maintenance
