3. Return lever 2b to the original position.
4. Close the front door of the tri-fold module.
Clearing Jams at Area 2e in the Tri-Fold Module
1. Open the front door of the tri-fold module.
2. Open the folder tray, move lever 2e to the right, then carefully remove the paper.
Note: If the paper is torn, remove all torn pieces of paper from the folder.
