3. Return lever 2f to its original position, then close the folder tray.
4. Close the front door of the tri-fold module.
Clearing Jams at Area 2g in the Tri-Fold Module
1. Open the front door of the tri-fold module.
2. Open the folder tray, move lever 2g to the right, then carefully remove the paper.
Note: If the paper is torn, remove all torn pieces of paper from the folder.
