3. Hold the tabs on both sides of the staple cartridge and pull the cartridge out of the finisher.
4. To remove the jammed staples, pull the staples in the direction shown.
WWaarrnniinngg:: The points of the jammed staples are sharp. Remove the jammed staples carefully.
5. Hold the tabs on both sides of the staple cartridge and insert the cartridge into the original position in the
finisher.
Note: If you have trouble inserting the cartridge, ensure that the staples are positioned correctly in the
cartridge.
Note: The booklet maker uses two staple cartridges. Booklet stapling requires that both staple cartridges
contain staples.
6. Repeat the procedure for the other staple cartridge.
7. Close the finisher side cover.
328
Xerox
®
AltaLink
®
B8145/B8155/B8170 Series Multifunction Printer User Guide
Troubleshooting

Xerox AltaLink B8145 Series Specifications

General

Print Speed	Up to 45 ppm
Print Resolution	Up to 1200 x 2400 dpi
Monthly Duty Cycle	Up to 200, 000 pages
Duplex Printing	Automatic
Touchscreen	10.1-inch color touchscreen
Functions	Print, Copy, Scan, Fax, Email
Memory	4 GB
Copy Speed	Up to 45 cpm
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Connectivity	Ethernet, USB
Scanning	Color scanning
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android, Mopria, Xerox Mobile Link App
Hard Drive	320 GB (optional)
