4. To open the staple cartridge clamp, pull the clamp in the direction shown.
5. Remove the jammed staples, then push the clamp in the direction shown until the clamp clicks into the locked
position.
WWaarrnniinngg:: The points of the jammed staples are sharp. Remove the jammed staples carefully.
6. Grasp the staple cartridge by the orange handle, then insert the cartridge into the stapler assembly until the
staple cartridge clicks into place.
7. Return the stapler assembly to the original position, then close the finisher door.
330
Xerox
®
AltaLink
®
B8145/B8155/B8170 Series Multifunction Printer User Guide
Troubleshooting
