Moving and Repacking the System
Phaser® 8510/8560MFP Multifunction Product
8-32
Removing the Document Feeder and Scanner
1. Remove the document feeder and scanner, pack them separately from the rest of the
system.
2. Disconnect the cable between the document feeder and the scanner.
3. Lift the document feeder.
a. Pinch the hinges, and then lift the document feeder away from the document glass.
8560-093
8560-071
1
2
