Xinje DS2 series User Manual

43
Unit
Default
Range
Suitable mode
Modify
Effective
1
reference unit
7
0~250
5
,
6
Servo
OFF
Immediately
Function: when the pulse error value is lower than P5
-
00, output /COIN signal.
Monito
r the pulse error
value via U-08.
1
0
/COIN
信号状态
偏移脉冲
（U-08)
P5-00
5-3-7. Positioning near (/NEAR)
Positioning near signal means the servo motor is near the positioning complete. It prompts
the device to prepare the next operation.
5-3-8. Command pulse prohibition (/INHIBIT)
To stop the commnad pulse counts in position control mode. When /INHIBIT signal is ON,
the command pulse stop counting.
Parameter
Signal
Def
ault
Meaning
Suitable
mode
Modify
Effective
P5
-
36
/NEAR
n.0000
Need to distribute
5
,
6
Any
Re
-
power
on
Note:
/NEAR
can be output from terminal by setting
P5
-
36, please see chapter 5
-
12
-
3
.
P5
-
04
Width of positioning near signal
Unit
Default
Range
Suitable mode
Modify
Effective
1
reference
unit
50
0~10000
5
,
6
Servo
OFF
Immediately
Function:
when the pulse error signal is lower than P5
-
04, output /NEAR signal.
Set the parameter wider than positioning complete signal. Monitor the pulse error value via U-08.
5-04
5-00
/NEAR
信号状态
0
1
1
0
/COIN
信号状态
偏移脉冲
（U-08)
Note: here is signal state, but not terminal state.
Error
pulse
(U-08)
/COIN
signal
Error pulse
(U-08)
/NEAR signal
state
/COIN
signal state
