Xirrus Wi-Fi Array XR4420 User Manual

Wi-Fi Array
Installing the Wi-Fi Array 81
 Load Balancing
 Broadcast
 Link Backup
 Bridged
 Mirrored
For more details on Gigabit port modes and their configuration, please see
“Network Interface Ports” on page 181.
Switch Failover Protection
To ensure that service is continued in the event of a switch failure, you can
connect Arrays to more than one Ethernet switch (not a hub).
Figure 30. Switch Failover Protection
See Also
Coverage and Capacity Planning
Deployment Examples
Installation Prerequisites
Network Management Planning
Planning Your Installation
Power Planning
Security Planning

Gigabit Ethernet connections must be on the same subnet.
Ethernet switch
Backup switch
Ethernet connections
