Wi-Fi Array
160 Viewing Status on the Wi-Fi Array
Statistics Windows
The following Array Statistics windows are available:
IAP Statistics Summary — provides an overview of the statistical data
associated with all IAPs. Expands to show links for displaying detailed
statistics for individual IAPs.
Per-IAP Statistics — provides detailed statistics for an individual IAP.
Network Statistics — displays statistical data associated with each
network (Ethernet) interface.
VLAN Statistics — provides statistical data associated with your assigned
VLANs.
WDS Statistics — provides statistical data for all WDS client and host
links.
Filter Statistics — provides statistical data for all configured filters.
Station Statistics — provides statistical data associated with each station.
IAP Statistics Summary
This is a status only window that provides an overview of the statistical data
associated with all IAPs. It also shows the channel used by each IAP. For detailed
statistics for a specific IAP, see “Per-IAP Statistics” on page 161. Click the Unicast
Stats Only checkbox on the lower left to filter the results, or clear the checkbox to
show statistics for all wireless traffic.
You can Refresh the data (update the window with the latest information) or
Clear the data (reset all content to zero and begin counting again) at any time by
clicking on the appropriate button. You can also click in the Auto Refresh check
box to instruct the Array to refresh this window automatically.
