Xirrus Wi-Fi Array XR4420

Wi-Fi Array
The Web Management Interface 117
User Interface
The WMI has been designed with simplicity in mind, making navigation quick
and easy. In the following example, you’ll see that windows are divided into left
and right frames.
Figure 42. WMI: Frames
Left frame Right frame Array info
Click to configure/view statistics
Log Message counters
Pull-down menu
Help
