Wi-Fi Array
82 Installing the Wi-Fi Array
Power Planning
All XR and XN Series Array models and XS16/8/4 Arrays support Power over
Gigabit Ethernet (PoGE) with an integrated splitter. AC power is also supported
on some versions of the XS8 and XS16.? True??
This section discusses the AC and PoGE power options.
AC Power
The AC power option requires a direct connection between the Array and a
dedicated AC power outlet. The power cord is provided with the unit.
Power over Gigabit Ethernet
To deliver power to the Array, you may use the optional XP1, XP2, or XP8 Power
over Gigabit Ethernet (PoGE) modules. They provide power over Cat 5e or Cat 6
cables to the Array without running power cables — see Figure 5 on page 14.
Specific models of the Array are compatible with specific PoGE modules. For
details, please see “Power over Gigabit Ethernet Compatibility Matrix” on
page 451.
See Also
Coverage and Capacity Planning
Deployment Examples
Failover Planning
Network Management Planning
Security Planning
When using Cat 5e or Cat 6 cable, power can be provided up to a distance of
100m.
