Doc. 20780_03 59
DPRO Passive-Infrared (PIR) PRO Series by Xtralis Planning and Commissioning Manual
Also, the Setting window provides you with additional information regarding the setting
options, as shown in the following figure:
The above example shows help information regarding the detector’s address.
To view the help information of any other field, simply place the cursor in the required field
and the information appears in the upper box.
To close the Setting window, click ( ).
NOTE!
If you attempt to close the Settings window before saving the changes
you make, the following message appears:
If you are sure you want to exit the window without saving, click (Yes);
otherwise, click (No) then save the changes you made.
10.3.4.2.2 Upload Settings
To upload settings to detector, follow these steps:
1. Make the changes you want to the fields you can change,
2. Click ( ). Successful upload is represented with ( ).
NOTE!
Make sure to click ( ) to save the changes you made; otherwise,
they are lost.
10.3.4.2.3 Factory Settings
You can reinstate the factory default configuration to the detector instead of the changes you
made in the following cases:
