60 Doc. 20780_03
Planning and Commissioning Manual ADPRO Passive-Infrared (PIR) PRO Series by Xtralis
The detector does not seem to work properly.
A previous version of the ADPRO PRO Windows® Software was used on the same
detector.
To display and use the factory default settings, follow these steps:
1. Click (Factory), the following message appears:
2. Click (Yes) to replace the values with the factory ones,
3. Click ( ) to save them in the detector’s configuration file.
10.3.4.2.4 Download Settings
To download the detector’s settings, follow these steps:
1. Make the changes you want,
2. Select the detector,
3. Click ( ).
The configuration status is represented with the following symbols:
: Uploading configuration
: Changed configuration
: Communication problem
: Downloading configuration
10.3.4.2.5 Copy Settings
To copy the settings of a detector and use them in another one, follow these steps:
1. Select the detector which settings you want to copy,
2. Click ( ),
3. Select the detector to which you want to apply the copied settings,
4. Click ( ).
10.3.4.2.6 Save Settings to CFG File
To save the configuration in the “CFG” sub-folder accessed through the ADPRO PRO
Windows® Software folder saved in the computer, follow these steps:
1. Make the changes you want,
To Next Page
