68 Doc. 20780_03
Planning and Commissioning Manual ADPRO Passive-Infrared (PIR) PRO Series by Xtralis
The window is divided into the following sections:
Connected Detectors (1): displays all connected detectors with information about
identification number, firmware version number and alarm counters.
Type (2): Each symbol indicates a status as follows:
( ): connected.
( ): not connected.
Log (3): Displays the actual log.
To generate a statistics file and save it, follow these steps:
1. Enter file name,
2. Click ( ) to start the viewing the transmitted data, it appears as in the example
below:
Note that a line is created for each detected event, along with the date and event
description.
