Yamaha F25A - Page 108

4-9
FUEL
E
CARBURETOR
2. Measure:
●
Float height a
Out of specification → Replace.
NOTE:
●
The float should be resting on the needle
valve, but not compressing it.
●
Take measurements at the midline of the
float, opposite the side it pivots on.
Float height:
14.0 ± 0.5 mm (0.55 ± 0.02 in)
