6-6
E
LOWR
PROPELLER SHAFT ASSY.
EXPLODED DIAGRAM
Step Procedure/Part name Q’ty Service points
6 Shift shaft plate 1
7 O-ring 1 6 × 4.3 mm
8 Oil seal housing 1
9 Dowel pin 3
10 Gasket 1
11 Water seal 1
12 Oil seal 2
13 Shift shaft 1
Reverse the removal steps for installation.
Not reusable
