Yamaha SRX700D - Front Suspension Removal

3-8
CHAS
FRONT SUSPENSION
FRONT SUSPENSION
23 Nm (2.3 m • kg, 17 ft • lb)
Å:
Q’ty
1
1
1
1
1
2
1
2
2
4
1
2
1
Remarks
Remove the parts in the order listed below.
Refer to “SKI”.
For installation, reverse the removal proce-
dure.
Order
1
2
3
4
5
6
7
8
9
10
11
12
13
Job name/Part name
Front suspension removal
Ski
Tie rod
Shock absorber
Cap
Steering arm
Ski column
Bushing
Washer
Control rod
Collar
Bushing
Connecting rod
Collar
Front arm
: 1 ESSO beacon 325 grease
or Aeroshell grease #7A
48 Nm (4.8 m • kg, 35 ft • lb)
Ç:
50 Nm (5.0 m • kg, 36 ft • lb)
Î:
56 Nm (5.6 m • kg, 40 ft • lb)
‰:
78 Nm (7.8 m • kg, 56 ft • lb)
Ï:
42 Nm (4.2 m • kg, 30 ft • lb)
ı:
